National Defense and Military Industry New Materials: Special Ceramics

I. Overview

Special ceramics, as a key branch of functional structural materials in the 21st century, have established an irreplaceable strategic position in the national defense and military industry due to their exceptional properties including high strength, high hardness, high-temperature resistance, corrosion resistance, and low density. According to the U.S. Department of Defense's "2021-2025 Materials Development Roadmap," the penetration rate of advanced ceramic materials in military equipment has increased from 12% in 2010 to 34% in 2022, clearly demonstrating its pivotal role in the modernization of weapon systems. China's "14th Five-Year Plan for National Defense Science and Technology Industry Development" has also listed high-performance ceramic materials as one of the seven key basic materials, highlighting the strategic importance the Chinese government places on this critical material.

From a materials science perspective, special ceramics achieve systematic optimization of mechanical, thermal, and chemical properties through high-purity inorganic compound raw materials and precision manufacturing processes. For instance, silicon nitride (Si₃N₄) ceramics exhibit an impressive flexural strength of 800-1000 MPa and a thermal expansion coefficient as low as 3.2×10⁻⁶/℃, maintaining structural stability under extreme temperature conditions. This significantly enhances the battlefield survivability of critical military equipment such as missile guidance heads and spacecraft thermal protection systems. In practical applications, SiC/C functionally graded materials have demonstrated outstanding performance in fusion device plasma welding, where their multi-layer composite structure effectively addresses material failure issues under high-energy particle bombardment. Notably, porous ceramics, with their low thermal mass and controllable permeability, are achieving precise microstructure regulation through direct foaming technology, providing innovative solutions for new-generation protective armor and lightweight projectile designs.

Currently, China's national defense science and technology industry faces a "bottleneck" in critical materials, necessitating systematic research into the structure-property relationships and engineering application pathways of special ceramics to overcome foreign technological blockades and achieve self-reliance and high-quality development.

II. International and Domestic Research Status

The U.S. Defense Advanced Research Projects Agency (DARPA) has led the "Ultra-High Temperature Ceramics (UHTCs) Program," developing ZrB₂-SiC composite ceramics. This material, primarily composed of carbides and silicides, exhibits excellent structural stability in 2000°C oxidizing environments, successfully applied in the thermal protection system of the X-37B spaceplane. Notably, during the 1990s SHARP (Spacecraft High-Temperature Advanced Reusable Structures) program, HfB₂/SiC, ZrB₂/SiC, and ZrB₂/SiC/C ultra-high temperature ceramics were evaluated through the Minuteman III intercontinental ballistic missile. Post-flight analysis revealed that cracks primarily resulted from internal particle agglomeration defects, though this flight test also confirmed the great potential of ultra-high temperature ceramics in extreme high-temperature environments. Currently, NASA Ames Research Center and DOE Sandia National Laboratories lead in HfB₂-SiC ultra-high temperature ceramic material research.

Tory Corporation in Japan has developed silicon carbide fiber-reinforced ceramic matrix composites (CMCs), which have been successfully applied to the hot-end components of the F-35 aircraft engine, increasing the turbine inlet temperature by 200°C and significantly enhancing engine high-temperature performance. On March 28, 2018, Tory Corporation announced a new carbon fiber composite material molding process—CFRP (Carbon Fiber Reinforced Plastics) vacuum pressure molding technology, which improves component dimensional accuracy while reducing energy consumption during the manufacturing process. On November 1, 2018, Tory Corporation announced the development of a new TORAYCAMX series carbon fiber with both high tensile strength and high tensile modulus. As one of the few developed countries after Japan to master carbon fiber production technology, the United States leads in carbon fiber and composite material applications globally.

In the EU's "Clean Sky 2.0" program, Safran Group has developed SiC/SiC composites using reaction infiltration technology, which have increased the thrust-to-weight ratio of aircraft engines by 15% through their high strength and high-temperature resistance, further advancing aviation propulsion system upgrades. France has a significant advantage in CVI (Chemical Vapor Infiltration) process technology, with Safran Group being one of the earliest companies to develop CVI technology. Safran has successfully implemented M88-2 engine nozzle external adjustment vanes through this technology.

Compared to international advanced levels, China's development of special ceramics still faces challenges. In ceramic material reliability evaluation systems, the Weibull modulus of certain materials is commonly below 15, indicating significant dispersion in strength distribution. Additionally, the ability to achieve dense sintering and defect control in large-scale, complex-shaped ceramic components remains to be improved. These technical bottlenecks restrict the broader application of high-performance special ceramics in military fields.

III. Applications of Special Ceramics in the National Defense and Military Industry

3.1 Applications in Aerospace

Special ceramics, with their unique high-temperature strength, oxidation resistance, and functional integration capabilities, have become indispensable key materials in the aerospace industry.

In thermal protection systems (TPS), the material selection for the nose cap of re-entry vehicles directly impacts aerodynamic thermal protection performance during atmospheric re-entry. Research shows that ZrB₂-SiC-ZrC ternary system ceramic matrix composites, through optimized phase composition and microstructure design, can operate stably for 120 seconds under 1650°C aerodynamic heating conditions, with a surface recession rate strictly controlled below 0.1 mm/s, significantly outperforming traditional SiC-based materials. This material system has been successfully applied in hypersonic vehicle thermal protection systems, with multiple flight tests confirming its excellent performance.

The rocket engine nozzle, as the core component of the propulsion system, requires materials that combine high-temperature resistance with anti-ablation properties. C/C-SiC composites, through carbon fiber reinforcement and gradient interface modification, have increased engine specific impulse by 8-12%. This material system has achieved long-term stable operation at 2200°C throat temperatures in the upper stage engine of the Long March 5 carrier rocket, marking a significant breakthrough in China's aerospace propulsion system material technology.

For hot-end component surface protection, 8% Y₂O₃-stabilized ZrO₂ (8YSZ) thermal barrier coatings, deposited on turbine blades through plasma spraying, can effectively reduce base temperature by 100-300°C, significantly extending the cycle life of engine hot-end components. Their low thermal conductivity (0.8-1.2 W/m·K) and phase transformation toughening characteristics provide reliable structural stability in high-temperature gas environments.

In integrated structural-functional components, ceramics achieve synergistic optimization of mechanical properties and functional characteristics through multi-physics field coupling design. In satellite bearing systems, silicon nitride (Si₃N₄) ceramic bearings exhibit a friction coefficient below 0.01 in vacuum environments due to their zero-lubrication friction characteristics, combined with self-lubricating coating design to achieve a service life of 10⁷ revolutions, providing high-precision, long-life transmission solutions for satellite attitude control systems. As the key window for spacecraft interaction with external space signals, BN-SiO₂ composite ceramics control the three-dimensional network structure of nano-scale BN whiskers to achieve a Ka-band (26.5-40 GHz) transmittance exceeding 90%, while maintaining a dielectric constant (ε) within the stable range of 3.5-4.5, meeting the stringent requirements for electromagnetic compatibility and signal transmission efficiency in next-generation high-resolution satellites.

The Al₂O₃-TiC ceramic reducer for space manipulator joints uses precision injection molding technology, achieving material densification and residual stress control through gradient sintering. It reduces weight by 40% compared to traditional metallic materials while increasing stiffness by three times, ensuring high-precision positioning during space station docking missions through its excellent dimensional stability.

3.2 Applications in Weapons and Equipment

Driven by the dual demands of lightweight equipment and enhanced protection efficiency, special ceramics have demonstrated unique application value in weapons and equipment due to their excellent mechanical properties and functional characteristics.

Armored protection systems represent the core application area for special ceramics. B₄C/Al composite armor, through interface enhancement and interlayer stress dispersion mechanisms, achieves an optimal balance between protection performance and weight. Experimental data shows that when face density is controlled at 35 kg/m², this material can effectively resist 7.62mm AP projectile penetration, meeting STANAG 4569 Level IV protection standards. Its multi-stage energy dissipation structure significantly outperforms traditional homogeneous armor systems. In practical applications, B₄C/Al composite armor has been successfully applied to multiple main battle tanks and armored vehicles, improving protection while reducing weight by approximately 60%, significantly enhancing equipment mobility.

In reactive armor design, the incorporation of AlN ceramic layers reduces the penetration depth of shaped charge jets by 60-70%, significantly improving reactive armor's anti-penetration capability through material phase change energy absorption and jet diversion effects. Helicopter cockpit protection systems achieve lightweight protection through SiC/polymer composite armor panels, whose layered composite structure meets MIL-STD-662F V50 standards, ensuring crew safety while reducing structural weight and creating conditions for improved equipment mobility.

In ammunition and fuze systems, special ceramics have also demonstrated significant advantages. For armor-piercing projectile cores, WC-Co ceramic matrix composites have made breakthrough progress in replacing depleted uranium cores. Their ultrafine grain strengthening and gradient interface design allow projectile core length-to-diameter ratios (L/D) exceeding 20 while maintaining structural integrity, with verified penetration performance of 800mm RHA armor plates. Piezoelectric fuze systems rely on the high piezoelectric efficiency of PZT-5H ceramics, generating trigger voltages exceeding 5kV under 20kN impact loads, meeting reliable detonation requirements in high-overload environments.

Missile guidance head windows utilize MgAl₂O₄ transparent ceramics, which through nano-scale microstructure control and surface coating technology achieve over 80% high transmittance in the 3-5μm mid-wave infrared band, while maintaining excellent anti-radiation and weather resistance, providing critical optical assurance for precision guidance systems.

3.3 Application Expansion in Other National Defense Fields

Special ceramics, with their unique physical and chemical properties, are playing a key role in emerging defense needs.

In naval sonar systems, PMN-PT-based piezoelectric ceramics demonstrate excellent performance. By adjusting the solid solution ratio of lead magnesium niobate and lead titanate, this material significantly improves electromechanical coupling coefficients and Curie temperature. Experimental data shows that PMN-PT piezoelectric ceramic transducers achieve a sensitivity of -180dB at 500Hz, a 30% improvement over traditional PZT ceramics, making them ideal candidates for next-generation low-frequency, high-power sonar systems. In underwater detection, positioning, and deep-sea resource exploration military missions, this material can effectively enhance detection range and target recognition accuracy, with proven anti-interference capabilities in complex acoustic environments.

In nuclear energy equipment, the neutron absorption properties of boride ceramics provide a new solution for reactor safety control. Boron carbide (B₄C), with its excellent thermal neutron absorption cross-section of 3840 barns, has become the preferred material for advanced nuclear reactor control rods. Compared to traditional control materials, B₄C-based ceramic composites not only offer higher neutron absorption efficiency but also maintain superior high-temperature mechanical properties (retaining over 85% flexural strength at 1600°C), significantly enhancing reactor operational safety under extreme conditions. In fast neutron reactors and fourth-generation nuclear reactor designs, this material achieves real-time dynamic adjustment of neutron flux through precise microstructure control, effectively solving swelling and cracking issues of traditional materials under high-temperature irradiation.

In electromagnetic protection, ceramic-based composite material technology breakthroughs have significantly enhanced the electromagnetic compatibility of defense equipment. The electromagnetic shielding compartment made from silicon carbide (SiC) fiber-reinforced ceramic matrix exhibits shielding effectiveness exceeding 60dB at 18GHz frequencies. This composite material combines the electromagnetic loss characteristics of conductive networks with the high-temperature resistance of ceramic matrices through fiber three-dimensional weaving and gradient structure design, achieving wideband electromagnetic shielding while maintaining structural strength. Test results show that this new material achieves a 40% improvement in comprehensive shielding effectiveness compared to traditional metal shielding layers across X-band to Ka-band frequencies, with its low density (2.3 g/cm³) reducing equipment weight by over 30%. This technology has been successfully applied to key military equipment such as unmanned aerial vehicle payloads, satellite communication terminals, and missile guidance heads, enabling stable operation of high-precision electronic devices in strong electromagnetic interference environments.

IV. Future Development Direction

With the continuous increase in performance requirements for special ceramics in the national defense and military industry, future research needs to achieve breakthroughs in material system innovation, manufacturing process optimization, intelligent functional development, and standardization construction.

In material system development, high-entropy ceramics and ultra-high temperature ceramics hold significant potential. (Zr,Hf,Ta,Nb)B₂-based high-entropy ceramics, through multi-principal element synergistic effects, can significantly improve high-temperature strength and oxidation resistance, suitable for extreme environments such as rocket engine nozzles and hypersonic vehicle thermal protection systems. HfC-TaC-based ultra-high temperature ceramics, with their excellent oxidation resistance and high-temperature mechanical stability, show great potential for applications above 2000°C. Further research into their phase transformation behavior and interface bonding mechanisms is urgently needed to expand their service temperature range.

In manufacturing technology, 3D printing provides a new pathway for complex-shaped ceramic component fabrication. However, current technology still faces bottlenecks in coordinating printing accuracy and sintering shrinkage rate. Future research should focus on optimizing slurry rheological properties and sintering process parameters, combining in-situ gradient sintering or gradient thermal field control technology to maintain printing accuracy within ±50μm and reduce sintering shrinkage below 5%. Simultaneously, developing new ceramic precursor materials with controllable shrinkage characteristics and combining topological optimization algorithms for lightweight biomimetic structures can provide technical support for manufacturing complex components such as missile guide vanes and armor elements.

In intelligent development, functional ceramic materials will significantly enhance equipment's real-time monitoring and adaptive capabilities. By embedding conductive phases such as carbon nanotubes into ceramic matrices, strain-sensitive smart ceramics with a gauge factor (GF) exceeding 200 can be developed, meeting precise micro-strain detection requirements. These materials can be applied to armored structural health monitoring or engine blade stress detection, enabling damage warnings through in-situ resistance changes. Future research should further explore the stability of conductive networks under multi-field coupling environments and develop functional phase dispersion technologies compatible with ceramic matrix properties.

.
